It is primarily used in the production of high-quality pharmaceuticals—such as antibiotics—and fine chemicals, as the mill can effectively meet the stringent requirements for product purity and fineness.
How it works
The negative pressure generated by compressed air draws the material in the hopper into the flat grinding chamber; high-velocity airflow (which can reach sonic or even supersonic speed) collides and presses against each other. Materials that reach the specified particle size move toward the center of the grinding chamber as their centripetal force weakens, and are then discharged with the airflow before entering the cyclone separator and dust collector.
Performance and features
Wide Material Applicability, Suitable for High-Demand Scenarios
The spiral jet mill is applicable for dry grinding of various materials with a Mohs hardness below 9, especially designed to meet the processing needs of hard, high-purity, and high-value-added materials, providing a stable and reliable solution for high-standard grinding scenarios.
Special Grinding Modes, Protecting Sensitive Materials
Supporting constant-temperature, low-temperature, and medium-free grinding modes, the equipment avoids material damage caused by high temperatures or medium contact, making it an ideal grinding device for heat-sensitive, low-melting-point, high-sugar-content, and volatile special materials.
Flexible Particle Size Adjustment, Convenient and Efficient Operation
The product enables flexible particle size adjustment with a D50 range of 2～100 μm, covering multiple fineness requirements. Featuring a design without rotating parts, it allows easy disassembly and cleaning, effectively enhancing the flexibility of production processes and overall operational efficiency.
Stable and Durable Structure, Optional Functions on Demand
The main body is machined from a single steel plate using CNC technology, with a weld-free structure ensuring equipment stability and durability. Optional online cleaning (CIP) and online sterilization (SIP) functions are available to meet higher-standard production requirements.
