Rubber Grinding Mill

categoryJURM

This type is a special equipment developed by our company for producing fine rubber powder in combination with waste tires at room temperature. It is the only grinding machine in China that can realize industrial batch production of 40-200 mesh fine rubber powder at room temperature. It is combined with shredding equipment, crushing equipment, wire separation equipment, etc. To form a complete production line for recycling waste tires at room temperature by pure physical methods, which has high economic and social benefits.

mailinfo@jacantech.com
messageI need solutions

Performance and features

Adjustable Gap Design, Precise Fineness Control

Adopts conical rotor and stator structure; the crushing gap (0.2~2mm) can be easily adjusted via a handwheel. It precisely controls product fineness according to production needs, adapting to 40~200 mesh fine rubber powder processing with flexible and efficient operation.

Dual Cooling System, Ensuring Stable Operation

Innovatively adopts water + air cooling combined structure, which can timely dissipate heat generated during operation, effectively controlling equipment temperature rise, avoiding material deterioration due to high temperature, and greatly improving the stability and reliability of continuous equipment operation.

Wear-Resistant Component Upgrade, Extending Service Life

Wear parts are made of high-hardness and wear-resistant cemented carbide, with a service life exceeding 6000 hours verified by industrial use. It reduces component replacement frequency and maintenance costs, lowers production interruption risks, and ensures the continuity of mass production.

Complete Production Line Adaptation, Realizing Resource Recycling

Capable of industrial mass production of fine rubber powder at room temperature, it can seamlessly integrate with shredding equipment, crushing equipment, steel wire separation equipment, etc., forming a complete set of production lines for waste tire recycling via physical methods at room temperature, facilitating resource recycling.

Technical Parameters

swipe_leftSwipe left on the table below to view more models
Parameters / Model JURM 800 1000 1200
Speed (r/min) 980 860 740
Feed particle size (mesh) 5~10 5~10 5~10
Discharge particle size (mesh) 40~200 40~200 40~200
Output (kg/h) 100~150 150~200 200~250
Main motor power (kW) 45 55 55
Feeding motor power (kW) 0.55 0.55 0.55
Circulating cooling water temperature (℃) ≤40 ≤40 ≤40
Pressure (Mpa) 1~1.5 1~1.5 1~1.5
Volume (m³/h) 5~7.5 6~10 8~14
Weight (t) 1.65 1.8 2.7

Note: The production capacity is closely related to the particle size, specific gravity, hardness, moisture and other indicators of the raw materials.
The above parameters are for reference only, please consult our engineers for details.
