It can efficiently, uniformly and rapidly disperse one or more phases into another continuous phase.
JWEB Series High Shear Dispersing Homogenizer
categoryJWEB
Performance and features
Core Functional Advantages
The high shear dispersing homogenizer can efficiently, uniformly and rapidly disperse one or more phases into another continuous phase, enabling homogeneous phase integration even when the original phases are immiscible with each other.
Working Principle Features
Relying on the high linear velocity generated by the high-speed rotation of the rotor and the strong kinetic energy brought by high-frequency mechanical effects, the equipment subjects materials to comprehensive actions such as intense mechanical and hydraulic shearing, centrifugal extrusion, liquid layer friction, and impact tearing in the narrow gap between the stator and rotor, thus completing the dispersion and emulsification process.
Process Adaptability
Under the coordination of corresponding process parameter control and an appropriate amount of additives, it can achieve instantaneous fine dispersion and emulsification of immiscible solid, liquid and gas phases, and obtain stable and qualified products after cyclic processing.
Industry Application Scope
The equipment is widely applicable to industries such as coatings, paints, inks and suspension concentrates (SC), and can meet the needs of core production processes such as material dispersion, grinding and emulsification in these fields.
Technical Parameters
| Model\Specifications | JWEB50 | JWEB200 | JWEB500 | JWEB1000 | JWEB1500 | JWEB2000 | JWEB4000 | JWEB8000 | JWEB18000 |
|---|---|---|---|---|---|---|---|---|---|
| Power kW | 2.2 | 4 | 7.5 | 11 | 18.5 | 22 | 37 | 55 | 90 |
| Processing Capacity L | 50 | 200 | 500 | 1000 | 1500 | 2000 | 4000 | 8000 | 18000 |
| Rotational Speed RPM | 3000 | 3000 | 3000 | 3000 | 3000/1500 | 1500 | 1500 | 1500 | 1500 |
Note: The production capacity is closely related to the particle size, specific gravity, hardness, moisture and other indicators of the raw materials.
The above parameters are for reference only, please consult our engineers for details.
