The hammer & Turbine mill is a general-purpose crushing equipment that uses high-speed rotating hammer blades to impact, shear and grind materials. Its core wearing parts such as tooth claws, movable hammer heads, hammers and grinding discs adopt a modular design, which allows for convenient assembly and disassembly as well as quick replacement.
The feeding system delivers materials evenly into the grinding chamber, where the materials are subjected to intense impact from the high-speed rotating grinding rotor disk. Simultaneously, they undergo the combined effects of multiple forces—including friction, shearing, and collision—between the stationary disk and the gear ring, enabling efficient grinding.
Depending on the material properties, the grinding rotor disk and stationary disk can be configured with different structural designs to meet the grinding requirements of various materials.
This equipment finds wide application in industries such as chemicals, inorganic salts, pharmaceuticals, food processing, pigments, dyes, pesticides, battery materials, minerals, and refractory materials.
The entire system adopts a closed crushing design, featuring low dust emission and low operating noise for a clean and pollution-free production process. With a compact structure and small footprint, the equipment is easy to disassemble and clean. Equipped with a program-controlled system, the operation process is simple and easy to understand, reducing labor costs.
Boasting low installed power and outstanding cost-performance ratio, it effectively controls production energy consumption. Supporting multiple installation combinations, it can flexibly meet different process requirements. Meanwhile, the motor can be optionally equipped with a belt drive to increase rotation speed, successfully solving the problem of lacking high-speed motors in well-known brands.
Explosion-proof design can be customized according to material characteristics, suitable for processing flammable, explosive, and oxidizable materials. It also offers multiple working condition designs (high-temperature, low-temperature, normal-temperature) combined with air or inert gas closed-circuit circulation systems, fully meeting the crushing safety and process requirements of special materials.
The core structure of the equipment is streamlined, not only occupying a small space but also featuring easy disassembly and cleaning, reducing the time and labor input for daily maintenance. The combination of program control and modular design ensures operational convenience while lowering long-term maintenance costs.
| Parameters / Model JCUM | 160 | 250 | 360 | 500 | 630 | 800 | 1000 |
|---|---|---|---|---|---|---|---|
| Grinding disc diameter (mm) | 150 | 250 | 350 | 500 | 600 | 720 | 1000 |
| Maximum speed (r/min) | 12000 | 7500 | 5550 | 3850 | 3200 | 2800 | 2250 |
| Power (kW) | 3~4 | 5.5~7.5 | 11~15 | 18.5~30 | 30~45 | 37~75 | 55~90 |
| Particle size (mesh) | 20~325 | 20~325 | 20~325 | 20~325 | 20~325 | 20~325 | 20~325 |
| Output (kg/h) | 5~50 | 15~200 | 25~500 | 30~1200 | 50~1800 | 60~2000 | 150~3500 |
Note: The production capacity is closely related to the particle size, specific gravity, hardness, moisture and other indicators of the raw materials.
The above parameters are for reference only, please consult our engineers for details.
