This type is mainly used for the coarse crushing of brittle and loose materials. It can be used in conjunction with a grinding mill to improve the grinding efficiency, or it can be used alone for coarse crushing, and can crush to less than 12mm. This type is small in size, low in energy consumption, and high efficiency. It is widely used for coarse crushing for low-hardness materials in the chemical, dye, pigment, additive, diatomaceous earth, food and pharmaceutical industries.
The hammer crusher is specially designed for brittle and loose materials, mainly used for coarse crushing processing. It can operate independently or be used with crushers to improve overall crushing efficiency, and the particle size of crushed materials can be controlled below 12mm.
Featuring a compact structure, low energy consumption, and high crushing efficiency, the equipment is easy to operate and stable in operation. While ensuring processing results, it effectively reduces comprehensive production costs, adapting to various small and medium-sized production scenarios.
Widely used in chemical, dye, pigment, additive, diatomaceous earth, food, pharmaceutical and other industries, it is especially suitable for the coarse crushing needs of various low-hardness materials, with outstanding scene compatibility and practicality.
Supporting two modes: independent coarse crushing and supporting collaborative operation, it can be flexibly switched according to the actual production process. It can not only meet the demand for independent coarse crushing but also integrate into the complete crushing production line to improve overall processing efficiency.
| Parameters / Model JHML | 250 | 400 | 560 | 800 |
|---|---|---|---|---|
| Inlet size (length x width, mm) | 120×160 | 160×250 | 220×260 | 300×360 |
| Max main shaft speed (rpm) | 3000 | 2500 | 2320 | 1600 |
| Turntable diameter (including blade, mm) | 250 | 370 | 560 | 800 |
| Number of blades | 24 | 36 | 48 | 64 |
| Motor power (kW) | 2.2 | 5.5 | 15 | 30 |
Note: The production capacity is closely related to the particle size, specific gravity, hardness, moisture and other indicators of the raw materials.
The above parameters are for reference only, please consult our engineers for details.
