The dual-shaft mixer is widely used in fields such as coatings, paints, inks and suspension concentrates (SC), and can perform the dispersion and grinding operations of materials.
Performance and features
Adaptability to Processes in Multiple Industries
It is widely applicable to multiple chemical industries such as coatings, paints, inks and suspension concentrates (SC), and can efficiently undertake the core dispersion and grinding processes of various materials.
Equipment Performance Orientation
It is a new type of high-efficiency mixing equipment with excellent material handling capacity, which can meet the high-efficiency operation requirements for mixing equipment in the field of chemical production.
Suitability for High-Viscosity Materials
Specially designed for the mixing needs of high-viscosity materials, it can promote materials to quickly achieve dispersion, dissolution and uniform mixing, ensuring high-quality results of material processing.
Coverage of Chemical Production Scenarios
It can be widely applied to the production processes of coatings, inks, pigments and other related chemical products, providing stable and reliable equipment support for the processing of various chemical products.
Technical Parameters
| Specifications/Model | JWME150 | JWME500 | JWME800 | JWME1000 |
|---|---|---|---|---|
| Agitator Tank Volume | 150 | 500 | 800 | 1000 |
| High-speed Motor Power kW | 7.5-11 | 18.5-22 | 22-37 | 30-55 |
| Low-speed Motor Power kW | 4-5.5 | 7.5-15 | 11-30 | 11-37 |
| High-speed Blade Diameter | 200 | 250 | 280 | 330 |
| Low-speed Agitator Diameter mm | 1500 | 1500 | 1500 | 1500 |
| High-speed Shaft Speed RPM | 1500 | 1500 | 1500 | 1500 |
| Low-speed Shaft Speed RPM | 90-120 | 60-120 | 120 | 120 |
| Maximum Lifting Stroke mm | 700 | 950 | 1000 | 1100 |
Note: The production capacity is closely related to the particle size, specific gravity, hardness, moisture and other indicators of the raw materials.
The above parameters are for reference only, please consult our engineers for details.
