The coaxial dual-shaft mixer is widely used in industries such as coatings, paints, inks and suspension concentrates (SC), and can efficiently complete the dispersion and grinding processes of materials.
Performance and features
Adaptability to Processes in Multiple Industries
Widely used in industries such as coatings, paints, inks and suspension concentrates (SC), it can efficiently undertake the core dispersion and grinding processes of materials in these fields.
Processing of High-Viscosity Materials
Specially suitable for the stirring and mixing of high-viscosity materials such as coatings and inks, it can targetedly solve the problem of difficult homogenization of high-viscosity materials during processing.
Frame-Type Stirring Prevents Wall Adhesion
Equipped with a frame-type stirring structure, it can effectively avoid material wall adhesion during the stirring process, ensuring equipment cleanliness and material mixing uniformity.
High-Speed Dispersion Improves Quality and Efficiency
Combined with high-speed dispersion function, it can achieve full mixing and dispersion of materials, helping products meet the quality standards required by processes in a short time.
Technical Parameters
| Specifications/Model | JWMC150 | JWMC300 | JWMC500 | JWMC1000 | JWMC1500 |
|---|---|---|---|---|---|
| Frame Agitator Motor Power kW | 4 | 5.5 | 7.5 | 11 | 15 |
| Agitator Speed RPM | 40 | 25 | 25 | 25 | 25 |
| Disperser Motor Power kW | 11 | 15 | 22 | 37 | 55 |
| Disperser Speed RPM | 1500 | 1500 | 1500 | 1500 | 1500 |
| Tank Capacity L | 150 | 300 | 500 | 1000 | 1500 |
Note: The production capacity is closely related to the particle size, specific gravity, hardness, moisture and other indicators of the raw materials.
The above parameters are for reference only, please consult our engineers for details.
